Phantom II Custom Black

18Hz up to 21kHz. 96 dB SPL.
Compact speaker
1.400 €
Devialet media

Finish: Wählen Sie Ihre Farbe

Matte Black
Devialet media

Zubehör: Finden Sie Ihr perfektes Match

Legs - Phantom IIPhantom II's standMehr erfahren
Nicht vorrätig
Cocoon Phantom Ultimate 98 dBCarrying caseMehr erfahren
Nicht vorrätig

Devialet Care: Garantieverlängerung hinzufügen

Devialet Care - Phantom IISchützen Sie Ihre Investition.Mehr erfahren
99 €
Einen Store finden
reassuranceFree returns and exchanges

Ultimative power und kompaktheit.

ABSOLUTE CONNECTIVITY.

Phantom II Custom boasts professional features such as Dante™ network and analog/AES input, is fully compliant with technical integrator requirements, and simply configurable through IP address webpages.

BESPOKE CONTROL.

Phantom II Custom is designed to be operated by third-party devices such as preamps, professional audio DSP, and matrix mixers. It also lets you control your sound system from your network infrastructure via Savant, Control4, Crestron or drivers.

FITS INTO ANY ENVIRONMENT, RELIABLY.

Among available solutions, Devialet chose Audinate's Dante™ network for its reliability in audio streaming on an ethernet network infrastructure. Dante™ helps Phantom II Custom** fit seamlessly into any existing setup, allowing up to 256 channels of HD audio to be streamed over standard ethernet cables. ** Dante™ technology natively integrated into Phantom II Custom.

Spezifikationen

Lautsprecher

1 x Aluminum Full-Range driver
2 x Aluminum Bass drivers

Digital-Analog-Wandler

Devialet DAC embedded in Devialet Intelligence Processor
24bits / 96kHz
THD: -112dB

Prozessor

ARM Cortex-A9 1.25GHz processor 512MB DDR3-1600 memory

Seitenverkleidung

Gehäuse: weiß RAL 9016
White matte stainless steel sides

Power Supply

IEC 100-240V ~ 50/60Hz

Exklusive Technologien

ADH3®; HBI2®; SAM2®; ACE2; EVO®

Dimensionen und Gewicht

Abmessungen

Breite: 219 mm | Höhe: 157 mm | Tiefe: 168 mm

Gewicht

4.3 kg

Leistung

Maximaler Schallpegel

98 dB SPL in 1 m Abstand

Verstärkungskraft

375 Watts RMS

Verstärkungsleistung

THD+N* : 0.001% | Sättigung : 0 | Rauschen 0 dB SPL in 1 m Abstand (*Total Harmonic Distortion + Noise)

Frequenzbereich (Bandbreite)

Frequenzbandbreite: 18Hz bis 21kHz (@-6dB)
Präzision des Frequenzverhaltens: ± 1dB von 25Hz bis 20kHz

Eigenschaften

Synchronisierung

Admin webpage through Ethernet
Unlimited amount of devices

Konnektivität

Network: Ethernet, Dante support
Inputs: Euroblock connector, configurable in
- AES/EBU 110 Ohms balanced digital input
- balanced analog mono input
IP control (Crestron, Control4)

Netzwerk

Ethernet RJ-45 10/100/1000 Mbps (Gigabit) Dual network interface, Dante audio streaming and IP control

Was ist im Lieferumfang enthalten

  • 1 Phantomreaktor 1 Netzkabel 1 Kurzanleitung zur Inbetriebnahme

Häufig gestellte Fragen

HOW CAN I CONFIGURE PHANTOM II CUSTOM?

Via an online configuration page (// ip_address), accessible via the IP address of your Phantom II Custom on the web browser of your choice. You can then select your inputs and make your adjustments.

DOES PHANTOM II CUSTOM HAVE A UNIVERSAL POWER SUPPLY, SO IT CAN BE USED WITH ANY WALL OUTLET?

Yes, Phantom II Custom has an IEC universal power supply (90-240 V ~ 50 / 60Hz).

IS PHANTOM II CUSTOM WATER RESISTANT?

Yes, Phantom II Custom is IP44 certified. It is protected against splashing water from all directions.
Alles ansehenAlles ansehen
Download ManualDownload Manual
